130mm Long T301 Cast Iron Guide Shoe
Part Number
58001
Manufacturer
PFB
Description
130mm Long T301 Cast Iron Guide Shoe
£85.00


130mm Long
Fixing Hole Centres- 185mm
Fixing Hole Centres- 185mm
| Part Number | 58001 |
|---|---|
| Comments | Total Shoe Loading: 2000kg Takes 153mm Guide Shoe Liners Part No. 33178, 33183, 33172, 33180, 33170, 33171 Rubber Buffer to Suit Guide Shoe Part No. 58011 |
| Manufacturer | PFB |
